Sennheiser SKP 100 G4 Plug-On Transmitter (B: 626 - 668 MHz)

Code: SEN/509527

$410.00

The Sennheiser SKP 100 G4 Plug-On Transmitter is a powerful plug-on transmitter that turns every wired dynamic microphone into a wireless transmitter for evolution wireless G4 100P Series systems. Note: B Block covers 626 to 668 MHz. Be sure to check the Sennheiser Frequency Finder for the best range to cover your needs!

Add to Cart

Found this item cheaper elsewhere? Let us know

ENQUIRE NOW

Out of Stock - Call for availability

Or get notified when back in stock

OK, we'll notify you when Sennheiser SKP 100 G4 Plug-On Transmitter (B: 626 - 668 MHz) is back in stock.

Overview
Specifications

What's In The Box?

SKP 100 G4 plug-on transmitter

2 AA batteries

Quick guide

Safety guide

Manufacturer declaration sheet

The Sennheiser SKP 100 G4 Plug-On Transmitter is a powerful plug-on transmitter that turns every wired dynamic microphone into a wireless transmitter for evolution wireless G4 100P Series systems. Featuring an updated high-contrast LCD display, blue sync LED, and a dedicated escape button, it can be used when paired with a dynamic microphone and portable receiver (sold separately) for capturing audio in live sound, broadcast, documentary, mobile journalism, film, business, and educational applications.

Features

High-contrast LCD display
Blue sync LED
Dedicated escape button
Sturdy metal housing
Enhanced frequency bank system with up to 12 compatible frequencies
Pilot tone squelch for eliminating RF interference when transmitter is turned off
Enhanced AF frequency range
Wireless synchronization of transmitter via infrared interface
User-friendly menu operation with more control options
Auto-Lock function avoids accidental changing of settings
HDX compander for crystal-clear sound
Operates on 2 standard AA batteries
Transmitter features battery indication in 4 steps
Wide range of accessories adapts the system to any requirement

Specifications

Frequency range	B: 626 - 668 MHz
Dimensions	Approx. 105 x 43 x 43 mm
Compander	Sennheiser HDX
THD, total harmonic distortion	≤ 0.9 %
Weight	approx. 195 g
Signal-to-noise ratio	≥ 110 dBA
RF output power	Max. 30 mW
Switching bandwidth	up to 42 MHz
Peak deviation	±48 kHz
Nominal deviation	±24 kHz
Operating time	Typically 8 h
Modulation	Wideband FM
Power supply	2 AA batteries, 1.5 V or BA 2015 accupack
Current consumption	at nominal voltage: typ. 180 mA with transmitter switched off: ≤ 25 μA
Input impedance	68 kΩ, unbalanced
Max. Input voltage	3.3 Veff
Powering	3 V battery / 2.4 V rechargeable battery
Transmission frequency	Max. 1680 transmitting frequencies, adjustable in 25 kHz steps 20 frequency banks, each with up to 12 factory-preset channels, no intermodulation 1 frequency bank with up to 12 programmable channels
AF frequency response	80 – 18,000 Hz
Temperature Range	-10 °C to +55 °C
Frequency stability	≤ ±15 ppm
